Class 1500 2500 Flanged Steam Trap

Class 1500 2500 Flanged Steam TrapClass 1500 2500 Flanged Steam Trap
Class 1500 2500 Flanged Steam Trap

Class 1500 2500 Flanged Steam Trap Product introduction

 Class 1500 2500 High pressure steam trap manufacturer, factory and supplier in China. Class 1500 2500 flanged steam trap for high temperature and high pressure saturation and steam main and turbine steam subcritical use. Automatic blowing device is installed inside the Class 1500 2500 flanged steam trap. New type valve disc, seal is very reliable. Steam insulation device, high efficiency and energy saving.

Class 1500 2500 flanged steam trap can quickly discharge the air and cold condensate when the equipment starts, with big displacement and small steam leakage rate. Strong corrosion resistance. Reliable action, durable. Within the range of working pressure, without adjustment, energy saving. Class 1500 2500 flanged steam trap is widely used in chemical, petrochemical, petroleum, paper, mining, power, food, pharmaceutical, mechanical equipment supporting, electronic industry and other steam fields.

Class 1500 2500 flanged steam trap feature:
1.Automatic blowoff mechanism is installed inside the valve. It is a new-type crown valve plate with reliable sealing,and steam heat preservation mechanism with hign-efficiency energy conservation.
2.Rapid air and condensate water exhaust while starting the equipment,great displacement and small steam leakage.
3.Strong anticorrosion,reliable operation and durability.
4.Free of adjustment and remarkable energy-saving result within the working pressure.

Class 1500 2500 flanged steam trap specification:
Product Name:
Class 1500 2500 High pressure steam trap
Pressure Rating: 1.6-42.0 Mpa,Class 150- Class 2500
Nominal Diameter: DN15-50 mm.
Body Material: cast steel,Stainless Steel,Alloy Steel.
Standard Flanges: DIN, ANSI, JIS, JB79.
Standard Screws:NPT,BSP.
Stand Welding:Socket Welded.

Class 1500 2500 flanged steam trap performance:
Maximum Working Temperature  ℃                550
Maximum Pressure Differential(Mpa) 15.0
Minimum Pressure Differential(Mpa) 0.3
